2600-205 VERSAPPLIER
For cargo hook equipped helicopters capable of 2200lbs. external loads
This hook-mounted, medium lift assembly is widely used for offshore spill
containment. Cyclic control allows pilot control of pump, electric motor-driven
boom valve, flow control, and operation of gasoline engine.
System Components
- Hopper: Durable fiberglass construction.
- Frame and Hardware: Epoxy coated aluminum support structure with stainless steel hardware for corrosion resistance.
- Boom Assembly: Booms can be rotated for desired nozzle position relative to airflow across orifices.
- Cyclic Control: Allows pilot control of pumps, boom valve, flow control and operation of gasoline engine.
- Boom Valves: Electric motor driven,provides negative pressure on boom in OFF position.
- Power Supply: Standard 6.5 HP 4-cycle gasoline engine (optional 24VDC electric motor powered by helicopter).
Specifications
| Net Weight | 265 lbs. |
| Gross Weight | 2265 lbs. |
| System Capacity | 250 gallons |
| Standard Power | 6.5 HP gasoline |
| Optional Power | 24VDC |
| Pump Capacity | 200 GPM |
| Boom Span | 30 feet |
| Spray Width | 15-100 feet |
| Nozzles | 58 total |
Optional hopper size, motors and pumps available.
Contact ISOLAIR for special application.
